Marin Four Corners 1

Buyers in the USA are responsible for arranging their own shipping. For more information, please contact the shop directly.

Marin Four Corners 1

Complete spec list and geometry available at Marin Bikes.

Frame

• Series 1 CrMo

• Size-Specific Wheels (XS, S = 650B; M, L, XL = 700C)

• Biometric Geometry

• Fender and rack mounts

• Disc mount

Fork

• Series 1 CrMo

• Fender, rack, and bottle cage eyelets

• IS disc mount

Wheels & Tires

• Rims: Marin aluminum, double wall, disc specific

• Hubs

• Rear: Forged aluminum alloy, disc, 32H

• Front: Forged aluminum alloy, disc, 32H

• Spokes: 14g black stainless steel

• Tires: Vee Tire Co. GPVee, 700/650 × 40

Drivetrain

• Rear Derailleur: Shimano Sora, 9-speed

• Front Derailleur: Shimano Sora

• Shift Levers: Shimano Sora ST300, 3×9-speed

• Crankset: Shimano Sora FC3030, 50/39/30T

• Bottom Bracket: Shimano

• Chain: KMC X9

• Cassette: Shimano HG200, 9-speed, 11–34T

Brakes

• Front Brake: Tektro Spyre-C Road mechanical disc, 160mm rotor

• Rear Brake: Tektro Spyre-C Road mechanical disc, 160mm rotor

• Brake Levers: Shimano (integrated shifters)

Cockpit

• Handlebar: Marin butted alloy, compact, 16º flared drop

• Stem: Marin 3D-forged alloy

• Grips: Marin Comfort bar tape, shock-absorbing gel pads

• Headset: FSA No.8D, sealed cartridge bearings

Seat & Post

• Seatpost: Marin alloy, 27.2mm

• Saddle: Marin MTB

Pedals

• Pedals: Trekking platform
